Hex Flange Self-Tapping Screws
Hex Flange Self-Tapping Screws are specialized fasteners designed for quick and secure installation in metal, plastic, and wood without requiring pre-drilled holes. The hexagonal flange head with an integrated washer provides improved load distribution and resistance to loosening, making these screws ideal for automotive, industrial machinery, construction, and sheet metal applications.
At Rajal Industries, we manufacture precision-engineered Hex Flange Self-Tapping Screws that conform to DIN and general self-tapping standards, ensuring high tensile strength, optimal thread engagement, and long-term performance.
Sizes & Standards
| Size Range | Standards |
|---|---|
| Diameters: M3 to M10 (Metric) | Same as self-tapping screw standards |
| Gauge Sizes: 6 to 14 (Imperial) | DIN 6928 – Standard for hex flange self-tapping screws |
| Lengths: 6mm to 50mm | Hex flange standards for improved clamping force |
Material & Strength Grades
| Material Type | Available Strength Grades | Industry Standards |
|---|---|---|
| Carbon Steel & Mild Steel | 4.6, 5.6, 8.8 | DIN 6928, Self-Tapping Standards |
| Stainless Steel (Corrosion Resistant) | A2-70 (SS 304), A4-80 (SS 316) | ISO 3506 |
| Hardened Steel (Heat Treated) | Class 8.8, 10.9 | DIN 6928, Self-Tapping Standards |
- Heat-Treated for Maximum Strength –Hex Flange Self-Tapping Screws undergo case hardening for enhanced drilling capability and wear resistance.
- Load Ratings Based on Material & Application:
- Carbon Steel Class 8.8 Hex Flange Self-Tapping Screw: 800-900 MPa tensile strength
- Stainless Steel A4-80 Hex Flange Self-Tapping Screw: 700-800 MPa corrosion-resistant strength
Head & Drive Design Specifications
Hex Flange Head for Secure Torque Application
- Provides high clamping force and prevents loosening under vibration.
- The integrated washer-like flange enhances load distribution and eliminates the need for a separate washer.
Self-Tapping Thread Profile for Quick Installation
- Designed to cut its own threads into metal, wood, or plastic without pre-drilling.
- Ensures maximum engagement and tight grip for secure fastening.
Precision Machined for High Load Distribution
- Available with sharp or blunt drilling tips, ensuring efficient penetration and fastening stability.
- Designed for fast installation in automotive, construction, and industrial applications.
Thread Specifications & Precision Engineering
| Thread Type | Description | Application |
|---|---|---|
| Coarse Thread (UNC/Metric) | Ensures quick penetration and high grip strength | Sheet metal, plastic, wood |
| Fine Thread (UNF/Metric Fine) | Provides stronger holding power & vibration resistance | Automotive, industrial enclosures |
| Fully Threaded Hex Flange Screws | Allows maximum engagement and improved clamping force | Structural panels, machinery parts |
| Partially Threaded Hex Flange Screws | Offers better shear strength & controlled load transfer | Vehicle assembly, heavy-duty fixtures |
Thread Fitment & Compliance
- Metric threads conform to ISO 6g tolerances, ensuring precise engagement with various materials.
- Imperial Hex Flange Self-Tapping Screws meet DIN 6928 for industrial and automotive use.
Common Applications of Hex Flange Self-Tapping Screws
- Automotive & Heavy Machinery – Used in engine components, chassis assemblies, and body panels.
- Sheet Metal Fabrication & HVAC Systems – Ensures strong fastening in ducts, enclosures, and steel structures.
- Construction & Industrial Framing – Provides secure mounting in metal-to-metal and wood-to-metal connections.
- Electrical & Telecom Equipment – Used in junction boxes, enclosures, and cable trays.
- Railway & Aerospace Engineering – Fastens lightweight metal panels and precision components.
Why Choose Rajal Industries for Hex Flange Self-Tapping Screws?
Manufactured to International Standards
Ensuring precision engineering, durability, and compliance.
Flange Head for Secure Fastening
Eliminates the need for separate washers, reducing installation time.
Customizable Designs
Ideal for automotive, industrial, and construction clients.
Bulk & Custom Orders
Ideal for automotive, electronics, and industrial clients.
High Retention Strength & Vibration Resistance
Engineered for long-term, maintenance-free fastening.
